FI-18 Series - Automatic Double Sided Final Inspection AVI System
InScan FI-18 is a compact and high performance fully automatic double sided AVI system for Final Inspection of PCB boards.

System advantages include:

  • Fastand easy job setup
  • Performing job setup is fast and easy. The setup is based on golden board and CAD data which greatly simplifies the setup process. Additionally, the setup process is fast and intuitive and can be completed in less than an hour.

  • High throughput
  • The FI-18 series inspects and processes a double sided board sized 210X300 mm 5.5 sec.

  • Superior interline high resolution CCD sensor
  • The state of the art sensor used by the FI-18 system enables both ultra fast scan times and high image quality.

  • Parallel double sided board inspection
  • The system's design includes four high resolution interline CCD sensors which performs parallel image acquisition asynchronously. This enables a dramatic cutback in the board inspection time, which in turn leads to high system throughput.

  • Automation ready hardware architecture
  • This architecture allows the customer to choose his preferred automation module: full automation, semi automation or standalone. The architecture is very flexible, and allows the user to upgrade the automation module at any given time, without the need to purchase a new system.

    Download data sheet
